Action menu – Watlow EZ-ZONE RMH User Manual
Page 61
Watlow EZ-ZONE
®
RMH Module
•
58
•
Chapter 4 Setup Page
RM High Density Module
•
Setup Page
Display
Parameter Name
Description
Range
Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data
Type
&
Read/
Write
[`o;Ct]
[ o.Ct]
Digital Output (1 to 12)
Control
Set the output control type.
This parameter is only
used with PID control, but
can be set anytime.
[`Ftb]
Fixed Time Base (34)
[`utb]
Variable Time Base
(103)
Fixed
Time
Base
1822
[offset 30]
0x6A
(106)
1 to 12
2
75
6002
uint
RWES
[`o;tb]
[ o.tb]
Digital Output (1 to 12)
Time Base
Set the time base for fixed-
time-base control.
0.1 to 60.0 for switched DC/
SSR, 5.0 to 60.0 for mechan-
ical relays
1824
[offset 30]
0x6A
(106)
1 to 12
3
76
6003
float
RWES
[`o;Lo]
[ o.Lo]
Digital Output (1 to 12)
Low Power Scale
The power output will nev-
er be less than the value
specified and will represent
the value at which output
scaling begins.
0.0 to 100.0
0.0
1836
[offset 30]
0x6A
(106)
1 to 12
9
77
6009
float
RWES
[`o;hi]
[ o.hi]
Digital Output (1 to 12)
High Power Scale
The power output will
never be greater than the
value specified and will
represent the value at
which output scaling stops.
0.0 to 100.0
100.0
1838
[offset 30]
0x6A
(106)
1 to 12
0xA (10)
78
6010
float
RWES
[`ACt]
[`SEt]
Action Menu
[``Fn]
[ Fn]
Action (1 to 24)
Function
Set the action that will be
triggered by this function.
[nonE]
None (61)
[USr;r]
User Settings Re-
store (227)
[ALM]
Alarm Reset (6)
[`SiL]
Silence Alarms (108)
[`AoF]
Control Loops Off
and Alarms to Non-alarm
State (220)
[`F;AL]
Force Alarm to Occur
(218)
[idLE]
Idle Set Point Enable,
level triggered (107)
[tUnE] Tune, edge triggered
(98)
[MAn]
Manual/Auto Mode,
level triggered (54)
[`oFF]
Switch Control Loop
Off, level triggered (90)
[`r;en]
Remote Set Point En-
able (216)
[`t;da]
TRU-TUNE+
®
Dis-
able, level triggered (219)
None
2184
[offset 20]
0x6E
(110)
1 to 24
3
113
10003
uint
RWES
[``Fi]
[ Fi]
Action (1 to 24)
Function Instance
Set the instance of the
function selected above.
0 to 24
0
2186
[offset 20]
0x6E
(110)
1 to 24
4
114
10004
uint
RWES
Note:
Some values will be rounded off to fit in the four-character display.
Full values can be read with other interfaces.
Note:
If there is only one instance of a menu, no submenus will appear.
** These parameters/prompts are available in these menus with firmware revisions 6.0 and
above.
R: Read
W: Write
E:
EEPROM
S:
User
Set
