Page 80
Watlow EZ-ZONE
®
RMH Module
•
77
•
Chapter 4 Setup Page
RM High Density Module
•
Setup Page
Display
Parameter Name
Description
Range
Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data
Type
&
Read/
Write
[sas;b]
[SAS.b]
Timer (1 to 24)
Source Active State B
Set what state will be read
as on.
[high]
High (37)
[LoW]
Low (53)
High
13202
[offset 50]
0x83 (131)
1 to 24
0xC (12)
- - - -
31012
uint
RWES
[``ti]
[ ti]
Timer (1 to 24)
Time
Set the time span that will
be measured.
0.0 to 9,999.0
1.0
13204
[offset 50]
0x83 (131)
1 to 24
0xD (13)
166
31013
float
RWES
[`LEu]
[ LEv]
Timer (1 to 24)
Active Level
Set which output state will
indicate on.
[high]
High (37)
[LoW]
Low (53)
High
13206
[offset 50]
0x83 (131)
1 to 24
0xE (14)
- - - -
31014
uint
RWES
[`Ctr]
[`Set]
Counter Menu
[``Fn]
[ Fn]
Counter (1 to 24)
Function
Set whether the counter in-
crements or decrements the
count value. Decrementing
0 returns 9,999. Increment-
ing 9,999 returns 0.
[``UP]
Up (1456)
[``dn]
Down (1457)
Up
12236
[offset 40]
0x82 (130)
1 to 24
9
- - - -
30009
uint
RWES
[SFn;A]
[SFn.A]
Counter (1 to 24)
Source Function A
Set the type of function
that will be used for the
counter clock signal.
[nonE]
None (61)
[ALM]
Alarm (6)
[`CPE]
Compare (230)
[`Ctr]
Counter (231)
[`dio]
Digital I/O (1142)
[Ent;A]
Profile Event Out A
(233)
[Ent;b]
Profile Event Out B
(234)
[Ent;C]
Profile Event Out C
(235)
[Ent;d]
Profile Event Out D
(236)
[Ent;E]
Profile Event Out E
(247)
[Ent;F]
Profile Event Out F
(248)
[Ent;g]
Profile Event Out G
(249)
[Ent;h]
Profile Event Out H
(250)
[`FUn]
Function Key (1001)
[`lgC]
Logic (239)
[tMr]
Timer (244)
[`uAr]
Variable (245)
None
12220
[offset 40]
0x82 (130)
1 to 24
1
- - - -
30001
uint
RWES
[`Si;A]
[ Si.A]
Counter (1 to 24)
Source Instance A
Set the instance of the
function selected above.
1 to 250
1
12224
[offset 40]
0x82 (130)
1 to 24
3
- - - -
30003
uint
RWES
Note:
Some values will be rounded off to fit in the four-character display.
Full values can be read with other interfaces.
Note:
If there is only one instance of a menu, no submenus will appear.
** These parameters/prompts are available in these menus with firmware revisions 6.0 and
above.
R: Read
W: Write
E:
EEPROM
S:
User
Set
