Watlow EZ-ZONE ® RMH Module • 73 • Chapter 4 Setup Page
RM High Density Module • Setup Page
Display
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data
Type
&
Read/
Write
[`iP;8]
[ ip.8] Linearization (1 to 24)
Input Point 8
Set the value that will be
mapped to output 8.
-1,999.000 to 9,999.000 °F or
units
-1,128.333 to 5537.223 °C
7.0 14408
[offset 70]
0x86 (134)
1 to 24
0xF (15)
136 34015 float
RWES
[`oP;8]
[ op.8] Linearization (1 to 24)
Output Point 8
Set the value that will be
mapped to input 8.
-1,999.000 to 9,999.000 °F or
units
-1,128.333 to 5537.223 °C
7.0 14428
[offset 70]
0x86 (134)
1 to 24
0x19 (25)
137 34025 float
RWES
[`iP;9]
[ ip.9] Linearization (1 to 24)
Input Point 9
Set the value that will be
mapped to output 9.
-1,999.000 to 9,999.000 °F or
units
-1,128.333 to 5537.223 °C
8.0 14410
[offset 70]
0x86 (134)
1 to 24
0x10 (16)
138 34016 float
RWES
[`oP;9]
[ op.9] Linearization (1 to 24)
Output Point 9
Set the value that will be
mapped to input 9.
-1,999.000 to 9,999.000 °F or
units
-1,128.333 to 5537.223 °C
8.0 14430
[offset 70]
0x86 (134)
1 to 24
0x1A (26)
139 34026 float
RWES
[iP;10]
[ip.10] Linearization (1 to 24)
Input Point 10
Set the value that will be
mapped to output 10.
-1,999.000 to 9,999.000 °F or
units
-1,128.333 to 5537.223 °C
9.0 14412
[offset 70]
0x86 (134)
1 to 24
0x11 (17)
140 34017 float
RWES
[oP;10]
[op.10] Linearization (1 to 24)
Output Point 10
Set the value that will be
mapped to input 10.
-1,999.000 to 9,999.000 °F or
units
-1,128.333 to 5537.223 °C
9.0 14432
[offset 70]
0x86 (134)
1 to 24
0x1B (27)
141 34027 float
RWES
[`CPE]
[`Set]
Compare Menu
[``Fn]
[ Fn] Compare (1 to 24)
Function
Set operator that will be
used to compare Source A
to Source B.
[`oFF] Off (62)
[``g;t] Greater Than (1435)
[``L;t] Less Than (1436)
[```E] Equal To (1437)
[``nE] Not Equal To (1438)
[`goE] Greater or Equal
(1439)
[`LoE]
Less or Equal (1440)
Off 11276
[offset 40]
0x80 (128)
1 to 24
9
171 28009 uint
RWES
[`toL]
[ toL] Compare (1 to 24)
Tolerance
If the difference between
Source A and Source B is
less than this value the two
will appear to be equal.
0 to 9,999.000 0.1 11280
[offset 40]
0x80 (128)
1 to 24
0xB (11)
172 28011 float
RWES
Note:
Some values will be rounded off to fit in the four-character display.
Full values can be read with other interfaces.
Note:
If there is only one instance of a menu, no submenus will appear.
** These parameters/prompts are available in these menus with firmware revisions 6.0 and
above.
R: Read
W: Write
E: EEPROM
S: User
Set
