Watlow EZ-ZONE ® RMH Module • 48 • Chapter 3 Operations Page
RM High Density Module • Operations Page
Display
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data
Type
& Read/
Write
[`Su;d]
[ Su.d] Math (1 to 24)
Source Value D
View the value of Source
D.
-1,999.000 to 9,999.000°F
or units
-1,128.000 to 5,537.000°C
6576
[offset 70] 0x7D
(125)
1 to 24
0x13 (19)
- - - - 25019 float
RWES
[`Su;E]
[ Su.E] Math (1 to 24)
Source Value E
View the value of Source
E.
[`off] Off (62)
[``on] On (63)
6578
[offset 70] 0x7D
(125)
1 to 24
0x14 (20)
- - - - 25020 uint
RWES
[oFSt]
[oFSt] Math (1 to 24)
Offset
Set an offset to be applied
to this function's output.
-1,999.000 to 9,999.000°F
or units
-1,110.000 to 5,555.000°C
0 6584
[offset 70] 0x7D
(125)
1 to 24
0x17 (23)
- - - - 25023 float
RWES
[``o;u]
[ o.v] Math (1 to 24)
Output Value
View the value of this
function's output.
-1,999.000 to 9,999.000°F
or units
-1,128.000 to 5,537.000°C
6582
[offset 70] 0x7D
(125)
1 to 24
0x16 (22)
- - - - 25022 float
RWES
No Dis-
play
Math (1 to 24)
Error
Read reported cause for
logic error
None (61)
Open (65)
Shorted (127)
Measurement Error (140)
Bad Cal Data (139)
Ambient Error (9)
RTD Error (141)
Fail (32)
Math Error (1423)
Not Sourced (246)
Stale (1617) 6596
[offset 70] 0x7D
(125)
1 to 24
0x1D (29)
- - - - 25029 uint
R
Note: Some values will be rounded off to fit in the four-character display . Full values
can be read with other interfaces .
If there is only one instance of a menu, no submenus will appear .
R: Read
W: Write
E: EEPROM
S: User Set
