Watlow EZ-ZONE RMH - Manual (Page 44)

Watlow EZ-ZONE ® RMH Module • 41 • Chapter 3 Operations Page
RM High Density Module • Operations Page
Display
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data
Type
& Read/
Write
[Mon]
[oPEr]
Monitor Menu
[C;MA]
[C.MA] Monitor (1 to 16)
Control Mode Active
View the control mode
currently in effect.
[`off] Off (62)
[AUto] Auto (10)
[MAn] Manual (54)
Off 4100
[offset 70]
0x97 (151)
1 to 16
2
- - - - 8002 uint
R
[`h;Pr]
[ h.Pr] Monitor (1 to 16)
Heat Power
View the heat output level
currently in effect.
0.0 to 100.0% 0.0 4124
[offset 70]
0x97 (151)
1 to 16
0xD (13)
- - - - 8011 float
R
[`C;Pr]
[ C.Pr] Monitor (1 to 16)
Cool Power
View the cool output level
currently in effect.
-100.0 to 0.0% 0.0 4126
[offset 70]
0x97 (151)
1 to 0x10
(16)
0xE (14)
- - - - 8014 float
R
[`C;SP]
[ C.SP] Monitor (1 to 16)
Closed Loop Working Set
Point
View the set point cur-
rently in effect.
-1,999.000 to 9,999.000°F
or units
-1,128.000 to 5,537.000°C
75°F 5232
[offset 80]
0x6B (107)
1 to 16
7
- - - - 8029 float
R
[`Pu;A]
[ Pv.A] Monitor (1 to 16)
Process Value Active
View the filtered process
value using the control
input.
-1,999.000 to 9,999.000°F
or units
-1,128.000 to 5,537.000°C
- - - - 422
[offset 90]
0x68 (104)
1 to 16
0x16 (22)
- - - - 8031 float
R
[Loop]
[oPEr]
Control Loop Menu
[`r;En]
[ r.En] Control Loop (1 to 16)
Remote Enable
Enable this loop to switch
control to the remote set
point.
[``no] No (59)
[`YES] Yes (106)
No 5260
[offset 80]
0x6B
(107)
1 to 16
0x15 (21)
38 7021 uint
RWES
[`C;M]
[ C.M] Control Loop (1 to 16)
Control Mode
Select the method that
this loop will use to con-
trol.
[`off] Off (62)
[AUto] Auto (10)
[MAn] Manual (54)
Auto 4100
[offset 70]
0x97
(151)
1 to 16
1
53 8001 uint
RWES
[A;tSP]
[A.tSP} Control Loop (1 to 16)
Autotune Set Point
Set the set point that the
autotune will use, as a
percentage of the current
set point.
50 to 200% 90 4138
[offset 70]
0x97
(151)
1 to 16
0x14 (20)
- - - - 8025 float
RWES
[`AUt]
[ AUt] Control Loop (1 to 16)
Autotune Request
Start an autotune. While
the autotune is active, the
Home Page of RUI will
display the tuning status.
When the autotune is
complete, the message will
clear automatically.
[``no] No (59)
[`YES] Yes (106)
No 4140
[offset 70]
0x97
(151)
1 to 16
0x15 (21)
54 8026 uint
RW
Note: Some values will be rounded off to fit in the four-character display . Full values
can be read with other interfaces .
If there is only one instance of a menu, no submenus will appear .
R: Read
W: Write
E: EEPROM
S: User Set
