Watlow EZ-ZONE ® RMH Module • 75 • Chapter 4 Setup Page
RM High Density Module • Setup Page
Display
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data
Type
&
Read/
Write
[`Er;h]
[ Er.h] Compare (1 to 24)
Error Handling
Select output value and er-
ror output state when com-
pare cannot be processed
[``t;g] True Good (1476)
[``t;b] True Bad (1477)
[``F;g] False Good (1478)
[``F;b] False Bad (1479)
False Bad 11282
[offset 40]
0x80 (128)
1 to 24
0xC (12)
- - - - 28012 uint
RWES
[tMr]
[`Set]
Timer Menu
[``Fn]
[ Fn] Timer (1 to 24)
Function
Set how the timer will
function.
[`oFF] Off (62)
[`on;P] On Pulse (1471)
[`dEL] Delay (1472)
[``o;s] One Shot (1473)
[`rET] Retentive (1474)
Off 13196
[offset 50]
0x83 (131)
1 to 24
9
165 31009 uint
RWES
[SFn;A]
[SFn.A] Timer (1 to 24)
Source Function A
Set the type of function
that will be used for this
source (run signal).
[nonE] None (61)
[ALM] Alarm Reset (6)
[`CPE] Compare (230)
[`Ctr] Counter (231)
[`dio] Digital I/O (1142)
[Ent;A] Profile Event Out A
(233)
[Ent;b] Profile Event Out B
(234)
[Ent;C] Profile Event Out C
(235)
[Ent;d] Profile Event Out D
(236)
[Ent;E] Profile Event Out E
(247)
[Ent;F] Profile Event Out F
(248)
[Ent;g] Profile Event Out G
(249)
[Ent;h] Profile Event Out H
(250)
[`FUn] Function Key (1001)
[`lgC] Logic (239)
[SoF;1] Special Function Out-
put 1 (1532)
[SoF;2] Special Function Out-
put 2 (1533)
[SoF;3] Special Function Out-
put 3 (1534)
[SoF;4] Special Function Out-
put 4 (1535)
[tMr] Timer (244)
[`uAr] Variable (245)
None 13180
[offset 50]
0x83 (131)
1 to 24
1
- - - - 31001 uint
RWES
[`Si;A]
[ Si.A] Timer (1 to 4)
Source Instance A
Set the instance of the
function selected above.
1 to 250 1 13184
[offset 50]
0x83 (131)
1 to 24
3
- - - - 31003 uint
RWES
Note:
Some values will be rounded off to fit in the four-character display.
Full values can be read with other interfaces.
Note:
If there is only one instance of a menu, no submenus will appear.
** These parameters/prompts are available in these menus with firmware revisions 6.0 and
above.
R: Read
W: Write
E: EEPROM
S: User
Set
