Watlow EZ-ZONE ® RMH Module • 87 • Chapter 4 Setup Page
RM High Density Module • Setup Page
Display
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data
Type
&
Read/
Write
[SFn;h]
[ SFn.h] Logic (1 to 24)
Source Function H
Set the type of function
that will be used for this
source.
[[nonE] None (61)
[ALM] Alarm (6)
[`CPE] Compare (230)
[`Ctr] Counter (231)
[`dio] Digital I/O (1142)
[Ent;A] Profile Event Out A
(233)
[Ent;b] Profile Event Out B
(234)
[Ent;C] Profile Event Out C
(235)
[Ent;d] Profile Event Out D
(236)
[Ent;E] Profile Event Out E
(247)
[Ent;F] Profile Event Out F
(248)
[Ent;g] Profile Event Out G
(249)
[Ent;h] Profile Event Out H
(250)
[`FUn] Function Key (1001)
[lim] Limit (126)
[`lgC] Logic (239)
[SoF;1] Special Function Out-
put 1 (1532)
[SoF;2] Special Function Out-
put 2 (1533)
[SoF;3] Special Function Out-
put 3 (1534)
[SoF;4] Special Function Out-
put 4 (1535)
[tMr] Timer (244)
[`uAr] Variable (245))
None 9354
[offset 80]
0x7F (127)
1 to 24
8
- - - - 27008 uint
RWES
[`Si;h]
[ Si.h] Logic (1 to 24)
Source Instance H
Set the instance of the
function selected above.
1 to 250 1 9370
[offset 80]
0x7F (127)
1 to 24
0x10 (16)
- - - - 27016 uint
RWES
[`S2;h]
[ SZ.h] Logic (1 to 24)
Source Zone H
Set the zone of the function
selected above.
0 to 16 0 9386
[offset 80]
0x7F (127)
1 to 24
0x18 (24)
- - - - 27024 uint
RWES
[`Er;h]
[ Er.h] Logic (1 to 24)
Error Handling
Select output value and er-
ror output state when logic
cannot be processed
[``t;g] True Good (1476)
[``t;b] True Bad (1477)
[``F;g] False Good (1478)
[``F;b] False Bad (1479)
False Bad 9408
[offset 80]
0x7F (127)
1 to 24
0x23 (35)
- - - - 27035 uint
RWES
Note:
Some values will be rounded off to fit in the four-character display.
Full values can be read with other interfaces.
Note:
If there is only one instance of a menu, no submenus will appear.
** These parameters/prompts are available in these menus with firmware revisions 6.0 and
above.
R: Read
W: Write
E: EEPROM
S: User
Set
