Chapter 4 Setup Page
RM High Density Module
•
Setup Page
Display
Parameter Name
Description
Range
Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data
Type
&
Read/
Write
[SFn;A]
[SFn.A]
Compare (1 to 24)
Source Function A
Set the type of function
that will be used for this
source.
[nonE]
None (61)
[``Ai]
Analog Input (142)
[CUrr]
Current (22)
[`C;Pr]
Cool Power, Control
Loop (161)
[`h;Pr]
Heat Power, Control
Loop (160)
[PWr]
Power, Control Loop
(73)
[`Lnr]
Linearization (238)
[MAt]
Math (240)
[``Pu]
Process Value (241)
[`SP;C]
Set Point Closed,
Control Loop (242)
[`SP;o]
Set Point Open, Con-
trol Loop (243)
[`uAr]
Variable (245)
None
11260
[offset 40]
0x80 (128)
1 to 24
1
- - - -
28001
uint
RWES
[`Si;A]
[ Si.A]
Compare (1 to 24)
Source Instance A
Set the instance of the
function selected above.
1 to 250
1
11264
[offset 40]
0x80 (128)
1 to 24
3
- - - -
28003
uint
RWES
[`S2;A]
[ SZ.A]
Compare (1 to 24)
Source Zone A
Set the zone of the function
selected above.
0 to 16
0
11268
[offset 40]
0x80 (128)
1 to 24
5
- - - -
28005
uint
RWES
[SFn;B]
[SFn.b]
Compare (1 to 24)
Source Function B
Set the type of function
that will be used for this
source.
[nonE]
None (61)
[``Ai]
Analog Input (142)
[CUrr]
Current (22)
[`C;Pr]
Cool Power, Control
Loop (161)
[`h;Pr]
Heat Power, Control
Loop (160)
[PWr]
Power, Control Loop
(73)
[`Lnr]
Linearization (238)
[MAt]
Math (240)
[``Pu]
Process Value (241)
[`SP;C]
Set Point Closed,
Control Loop (242)
[`SP;o]
Set Point Open, Con-
trol Loop (243)
[`uAr]
Variable (245)
None
11262
[offset 40]
0x80 (128)
1 to 24
2
- - - -
28002
uint
RWES
[`Si;B]
[ Si.b]
Compare (1 to 24)
Source Instance B
Set the instance of the
function selected above.
1 to 250
1
11266
[offset 40]
0x80 (128)
1 to 24
4
- - - -
28004
uint
RWES
[`S2;B]
[ SZ.b]
Compare (1 to 24)
Source Zone B
Set thezone of the function
selected above.
0 to 16
0
11270
[offset 40]
0x80 (128)
1 to 24
6
- - - -
28006
uint
RWES
