5. Flow and Commands of Basic MECHA

TROLINK Communication


208

5.4 Supported

Commands

Each controller of the MECHATROLINK communication specification supports the commands explained in [1] to
[6] below.

[1] NOP commands

Command Code

Name

NOP

00H

Command with no instruction

This command is to be used for network administration.
When this command is sent, the current condition of the slave (ALARM field and STATUS field) is returned.
You can check if the process is completed by checking CMDRDY=1 in the STATUS field.

y Communication data format

Byte Command

Response

0 CDRW(03H) ACK(01H)

1 NOP(00H) NOP(00H)

2 0

ALARM

3 0

4 0

5 0

0

: 0

0

15 0

0

16 WDT

RWDT

17 0

0

: 0

0

31 0

0

STATUS
