4. SCON-CA


132


(1) PLC address configuration (When the DATA_RWA command is in use)

Parameter

No. 84

SCON-CA DI

(port number)

PLC output address

[

Bytes]

SCON-CA DO

(port number)

PLC input address

[

Bytes]

5 (Lower byte)

5 (Lower byte)

0

0 to 15

6 (Upper byte)

0 to 15

6 (Upper byte)

(Note) Pay attention to use of duplicate node addresses.

(2) I/O signal assignments for each axis

An I/O signal of each axis consists of 1 word (2 bytes) of I/O addresses.

y Each channel is controlled by turning ON/OFF signal of each applicable bit.




















PLC output address

PLC input address

Bytes

2 bytes = 16 bits

2 bytes = 16 bits

Controller
input port
number

Controller
output port
number

Lower byte

Upper byte

Lower byte

Upper byte
