4. SCON-CA


166















































PLC input address
Bytes

2 bytes = 16 bits

Controller
output port
number

Cannot be
used.

Current
position
(upper word)

Current
position
(lower word)

Command
current
(upper word)

Command
current
(lower word)

If the current position is a negative value, it is expressed by a 2’s complement.

Lower byte

Upper byte

If the current force feedback data is a negative value, it is expressed by a 2’s complement.
