4. SCON-CA


160























































PLC input address
Bytes

2 bytes = 16 bits

Current
position
(upper word)

Current
position
(lower word)

If the current position is a negative value, it is expressed by a 2’s complement.

Command
current
(upper word)

Command
current
(lower word)

Current speed
(upper word)

Current speed
(lower word)

Alarm code

Status signal

If the current force feedback data is a negative value, it is expressed by a 2’s complement.

Lower byte

Upper byte
