4. SCON-CA


128


x PLC

output

o SCON-CA input

SCON-CA DO and output data resister

PLC output address

(When the DATA_RWA

command is in use)

Bytes

Position/simple direct

mode

Half direct mode 2

Remote I/O mode 3

Half direct mode 3

5

6

Port number 0 to 15

7
8

Target position

Target position

Target position

9

10

Specified position

number

11
12

Control signal

Positioning band

Positioning band

13
14

Speed

Speed

15
16

Acceleration/

deceleration

Acceleration/

deceleration

17
18

Push-current limiting

value

Push-current limiting

value

19
20

Control signal

Control signal

(Note) Pay attention to use of duplicate node addresses.
