4. SCON-CA


124


4.3.2 Monitor LED Indications

The operation condition of the communication board, as well as the network condition, can be checked using the
two LEDs provided on the front side of the board.

٤ : Illuminating, ˜ : OFF, ڏ : Flashing

LED Color

Indicator

condition

Description

Green

٤

CONNECT received (Connected to the master)

Red

٤

Communication error detected

STATUS 1

˜

The board is not connected to the master unit.

Green

٤

The board is operating properly.

Red

٤

A communication hardware error was detected when the board was not
yet ready.

STATUS 0

˜

The board is not yet ready or the power is not supplied.
