background image

5. Flow and Commands of Basic MECHA

TROLINK Communication


206


5.2

MECHATROLINK Data Link Layer

MDS is the only data link layer command supported under the MECHATROLINK communication specification.

MDS command

The intelligent I/O slave returns the following responses.

Byte Command

Response

0 MDS

(04H)

S(0)(90H)

1 0

ID_L(0H)

2 0

ID_H(80H)

3 0

0

4 0

0

: 0

0

15 0

0

16 0

0

17 0

0

: 0

0

31 0

0


5.3

MECHATROLINK Applied Layer

The command format for the MECHATROLINK applied layer is shown below.
[Refer to 5.4 “Supported Commands.”]

Byte Command

Response

0 CDRW(03H)

ACK(01H)

1

CMD

[Insert one of the

commands explained in

5.4 [1] to [6].]

RCMD

[Refer to 5.4 [1] to [6].]

2

ALARM field

[Refer to “Alarm Field”

on the next page.]

3

4

STATUS field

[Refer to “Status Field”

on the next page.]

5

:

15

16

Applied layer command

data

Applied layer response

data

17

:

31

Applied layer command

data

Applied layer response

data
