5. Flow and Commands of Basic MECHA

TROLINK Communication



207

 ALARM

Fields

One of the following error codes is set according to the communication status.

Error

code

Meaning/Name Description/Cause

Occurrence

phase

Transition

destination

phase

STATUS.ALM

/.WARNG

00H Normal

communication

01H

Invalid Command

Command that cannot be used

P1,2,4

As is

WARNG

02H Command

Not

Allowed

Command not consistent with
the communication phase

P2 As

is

WARNG

03H Invalid

Data

Data in the command is not
valid.

y Data outside of the setting

range

y Data outside of the

allowable range

y Data that is not supported

P2 As

is

WARNG


œ STATUS

Fields

The current status of the slave is set.

BIT15 BIT14 BIT13 BIT12 BIT11 BIT10 BIT9 BIT8

ERR_CODE

BIT7 BIT6 BIT5 BIT4 BIT3 BIT2 BIT1 BIT0

ERR Not

used

CMDRDY

WARNG

ALARM


Name Value

Description

ERR-CODE

If there is a controller error, check the error code in the troubleshooting section of
the operation manual for the controller unit, and take necessary actions.

1

A controller error is present.
Refer to the ERR-CODE fields.

ERR

0 Operating

properly

1

A command can be received.

CMDRDY

0

Busy condition
Commands received are discarded.

1

Minor trouble
Check if the command can be used in the current phase.

WARNG

0 Operating

properly

1

A communication error is present.
Communication error, communication part failure, or operational trouble or error

ALARM

0 Operating

properly
