44
5. Option
5. Option
5.1 Absolute Reset Jig
This jig is used to perform an absolute reset in the event that absolute data in the encoder was lost.
Model name
Model
number
Remarks
JG-1 For arm length 500/600 IX-NNN50
H/60 H/70 H/80 H
IX-NNC50 H/60 H/70 H/80 H
IX-NNW50 H/60 H/70 H/80 H
JG-3 For arm length 700/800
IX-NSN5016H/6016H JG-4 For high-speed type 500/600
5.2 Flange
This flange is used to install a load at the end of the Z-axis arm.
Model name
Model
number
Remarks
IX-FL-1 For arm length 500/600 IX-NNN50 H/60 H/70 H/80 H
IX-NNC50 H/60 H/70 H/80 H
IX-NNW50
H/60 H/70 H/80 H
IX-FL-3 For arm length 700/800
IX-NSN5016H/6016H IX-FL-2 For high-speed type 500/600
