IAI America IX-NSN6016H - Manual (Page 120)

112
12. Inspection/Maintenance
(5) Secure the cover (base) using the countersunk head screws [1]. (Tightening torque: 0.74 N ‚m)
z When installing the cover (base), be careful not to pinch the internal wiring
Instead of tightening to the specified torque in one go, loosely
position each screw in the position shown to the left, and while
pressing the cover in the direction of the arrow tighten both
screws uniformly to secure the cover effectively with the gasket.
Warning
[1] 6-M3 x 8
