Connecting Accessory Devices
4-12 SwingSmart DC Installation and Reference Manual Revision E
13 Loitering Alert Indicates a vehicle or loitering on the Outside Obstruction Loop. Adjustable from 0 delay to
135 seconds delay in 15-second time intervals.
Note: LT - LOITERING ALERT adjustments can be made in the Installer Menu.
14 Gate nearing full travel output Activated when the gate is three feet from full travel in both the open and close directions.
This output is used to reduce the sensitivity of a proximity sensor near the ends of gate travel.
15 Gate Failure output Activated to report occurrence of a problem. Indicates the system is in an Error Mode, Fault
Mode or Entrapment Mode. If active, the gate is disabled.
16 Motor Running output Active when the motor is running and the gate is in motion.
17 AC Power Failure output This relay is normally energized and drops with loss of AC power.
18 DC Power Failure output Activated when the battery power is very low, but the output ceases when the battery is dead.
The relay is triggered when the battery is less than 20 Volts.
19 Flasher Relay Controls flashing lights that pulse once per second. The relay is constantly activating except
when the open limit switch is triggered.
20 Free Exit Loop Vehicle Detector
output Active whenever the Exit Loop is tripped.
21 Inside Obstruction Vehicle
Detector output Activated when the Inside Obstruction Vehicle Detector is tripped.
22 Reset/Shadow Loop Detector
output Activated when the Center (Shadow) loop detector is tripped.
23 External Latching Gate Lock
Output Not functional in the SwingSmart operator.
24 Gate at Partial Open Position Not functional in the SwingSmart operator.
25 DC Power Alert Deactivates when the software detects a low battery voltage (below 21VDC, but greater than
18VDC) for a duration of 2 seconds or more. To slow battery drain, accessory power loads are
shed. Connect wiring to Relay 2, and then program the Installer Menu item Relay 2 Logic by
entering the number 25 in its data field.
Table 4-3. User-Programmable User Relays - Function Options (Continued)
No. Name Description
