Connecting a Radio Receiver for Remote Open

6-2

SwingSmart DC Installation and Reference Manual

Revision E

Note:This terminal is the same as the input terminal labeled RADIO OPEN along the left edge of the Smart
DC Controller.

6. Mount an external antenna onto the top of a fixed fence post near the operator.

7. Connect the antenna into the socket on the radio receiver.

8. Set the “DIP” switches in the receiver to match the same code used in the transmitter.

NOTE

If an edge sensor transmitter is also used to reverse the gate, be certain to use a two channel
commercial receiver. The edge and hand held transmitters must have their codes set to match
the receiver or they will not function.
