Run Mode
Revision E Display and Menu Options 3-7
Viewing Operator Status Displays
Eight operator status displays appear in two second intervals and show pertinent information which provides a
quick overview of the operator’s status or configurations. Refer to Figure 3-6.
NOTE
Items shown inside the brackets < > are variables that may change depending on operator con-
figurations. The examples shown in Figure 3-6 may appear differently on your operator.
Figure 3-6. Operator Status Displays
SOFTWARE VERSION
H5.##
DUAL GATE
OT <12>D
SWINGSMART DC20
HAND
UC <2>
USAGE CLASS
BT <0>
STANDARD BATTERY
D <32>.0 VDC
BATTERY VOLTAGE
CC<002600>
CYCLE COUNT
The software version and revision
number are hard-coded in the Smart
DC Controller. Displays the software version when
you press RESET or cycle power. You
will need the software version when
calling Technical Support.
Variables Description
MASTER or SLAVE
(This display only appears when the
operator is used in bi-parting gate
systems.) Indicates, in a dual gate setting,
whether the operator is set to Master
or Slave. The setting is assigned in the
Installer Menu.
1, 2, 3, 4, 5, 6, 7 and
11, 12, 13, 14 Indicates the software configuration
number which is preset at the factory
and cannot be changed.
LEFT or RIGHT Designates which way a gate opens
viewed from the operator. If it swings
to the left, it is a left-hand gate. Gate
handing is established in the initial
Setup Menu.
1, 2, 3, or 4 Displays the operator’s Usage Class
designation per UL 325 standards.
Refer to
Identifying Gate Operator
Category and Usage Class .
0, 1, or 2
0 = 8Ah
1 = 50Ah (Extended)
2 = 110Ah (Maximum) Confirms the operator’s battery type
which is assigned through the Installer
Menu.
Number varies depending on the
voltage that the charger is providing. Displays the actual voltage that the
batteries are delivering to the Smart
DC Controller.
Number varies depending on open
and close cycles. One cycle equals a
full open and close sequence. Displays the number of cycles the gate
operator has incurred. Similar to an
odometer, it resets to zero after
999,999 cycles.
