Installer's Check List
Intro-4 SwingSmart DC Installation and Reference Manual Revision E
I
NSTALLER
'
S
C
HECK
L
IST
The following list provides a high level overview of the tasks involved in installing the SwingSmart DC gate
operator. Take a moment to review the list and check off the items as you complete the install.
?
 Site Prep - concrete pad location/dimensions/distance from gate, conduits and vehicle detector loops
properly installed, gate bracket and linkage arm mounting considerations.
?
 Make sure gate installation complies with ASTM F2200 Specification for Automated Vehicular Gate
Construction and UL325 Safety Standards. Install supplied WARNING signs on both sides of the gate.
?
 Check for compliance with local codes, site conditions, and NEC standards.
?
 Install operator on concrete pad using four ½ - 13 x 3.5 inch long concrete wedge anchors.
?
 Temporarily attach gate bracket and linkage arm(s).
?
 Adjust open and close limit switches through manual operation of the gate.
?
 Complete gate arm installation (weld or drill and bolt).
?
 Cut the excess off the over extension stop (angle iron) on the SwingSmart arm.
?
 Hand-tighten the taper clamp to obtain a tight clutch setting.
?
 Install the earth ground and AC wiring connections for AC power.
?
 Connect battery wire to switch.
?
 Complete Initial Setup Menu programming.
?
 Review the connections on the Smart DC Controller.
?
 Install Master/Slave operator connections, if the site is a bi-parting gate system.
?
 Attach accessory devices.
?
 Configure the User and Installer Menu options. Program applicable settings dependent on accessory
devices installed.
?
 Set the Close Timer (in the User Menu), if necessary.
?
 Check the Smart DC Controller software version. If needed, upload the latest version from
www.hysecurity.com. See Smart Touch Analyze and Retrieve Tool (S.T.A.R.T.).
?
 Give a copy of the operator instructions to the end user. Show the end user how to:
• Remove the operator covers. Turn the power off and on.
• Turn the DC power switch off, which disengages the motor.
• Loosen the taper clamp and manually push the gate(s) open & close.
Note: Remember to re-tighten the taper clamp before turning the DC power switch back on and
replacing the covers.
• Test the red Emergency Stop Button located on the side of the control box. It can be accessed through a
hole in the cover. See illustration on page S-8.
?
 Take photographs of the completed installation site and save them in your business files.
