Controlled Products Systems Group 6003-080 User Manual
Actuator arm and control box mounting, Ul 325 compliant

Actuator Arm and
Control Box Mounting
6003
6003
6003
Copyright 2009 DoorKing, Inc. All rights reserved.
TM
Copyright 2012 DoorKing, Inc. All rights reserved.
Vehicular Swing Gate Operator
UL 325 Compliant
To wire this operator and complete the installation, refer to a specific control box “Wiring/Owner’s manual”.
OP
EN
CLO
SE
6003-065-Q-2-12
