MCNConfig Program: Receivers Resource Window
95 68-12286-110
Entries in the Receivers Window have the fields shown below. Some fields may not be visible in the
window depending on (a) the options licensed in the system and (b) the settings in the View menu item.
NI
Network Interface for this hardware module. This is a read-only field and is defined in the
Hardware window.
Grp:Mod
The MCN Group & Module number for legacy MCN devices. This is a read-only field defined
in the Hardware Window. The order of modules follows the module order in the Hardware
window.
Type
The IP Comparator Type (GCM 8000, MLC 8000 Analog Comparator, Mixed Mode) or legacy
MCN Module Type (CIB, AIB, IOB Std, IOB 2 Bit, IOB 1 Bit, etc.) for the hardware module.
This is a read-only field that is controlled in the Hardware Window
Channel
The radio channel for the hardware module. Read-only field (defined in Hardware list).
Rx
The Receiver Number for this receiver. This is a sequential number for a particular receiver
within its module or comparator. Read-only field. The maximum receiver number in a module
is based on the Bank number in the Hardware list.
For GPIO modules, this is a point number within the module.
MLC ID (MLC 8000 Analog Comparators and Mixed Mode Systems only)
This is the identifier for the MLC 8000 Analog Comparator port that is associated with this
receiver or BR.
It must be entered for all active receivers in these types of systems.
This field is found in the MMC_Cfg.csv file generated by the MLC 8000 Analog Comparator
CT program. See MLC 8000 Analog Comparator Interfacing on page 44 for details.
Name
Receiver site name (ex: North Tower, VA Hospital, etc.) or I/O point name.
Free-format text field. Change the Name by selecting the cell and typing in the name.
You can also cut & paste descriptions from Excel. See Using the Clipboard from other
Applications on Page 116.
Description
Free format text field for general customer use. Many customers use this field to store an
identifier for the leased line, microwave channel, or T1 channel bank and channel number for
this receiver. This field is not required for program operation. The Description field can be
used for additional information in error logging detail lines.
You can also cut & paste descriptions from Excel. See Using the Clipboard from other
Applications on Page 116 for more details.
Tag-1
This is a free-format user defined field. It is used with the TPCI option. You can use it as a
note field if you are not using the TPCI Option.
Tag-2
This is a free-format user defined field. It is used with the TPCI option. You can use it as a
note field if you are not using the TPCI Option.
