Installation
27 68-12286-110
HW Setup - Network Interface Setup
The first time HW Setup is ran, it sees that there is no Network Interface defined on the PC. It will ask
you what type of Network Interface (NI) you plan to use.
(The number of options in the "Available Types" list will vary by system.
Most systems will not show the PCLTA, LPP or virtual serial port entries.)
Select the type of Network Interface you intend on using with your system, from the list of possible
types available. Wee the indicated manual sections for further instructions:
Network Interface
Type Description
IP Comparator(s) Choose this if you have one or more of the following Motorola Solutions comparators:
GCM 8000 or MLC 8000
(either stand-alone or in a Mixed Mode configuration)
See the HW Setup – IP Comparator Network Interface section on page 30 for details
(Also see Note 1 below.)
HIB-IP(s)
and
HIB-IP 8000(s) Legacy Remote Network Interface that connects to the PC through an IP channel
See the HW Setup – HIB-IP Legacy Network Interface section on page 30 for details.
(Also see Note 1 below.)
HIB-232 – COMx Legacy non-dial-up HIB-232 units
- HIB-232 units connect to a COM port directly
or through external leased-line modems or equivalent.
See HW Setup – Legacy HIB-232 (non dial-up) section on page 31 for details.
PCLTA Legacy internal board in the PC. (32-Bit Windows only).
The MCN network will connect directly to this board.
If there is a PCLTA board that is properly installed, the HW Setup program will list it in
the "Possible Types" list.
See: HW Setup - Legacy PCLTA Setup – 32 Bit Windows only on page 33 for details.
Note 1: You will need to set up parameters for the IP Comparators and/or HIB-IP units in the system
configuration files by using McnConfig Server program. You will also have to download settings to the
HIB-IP from the McnConfig Server program.
After you have selected the proper Network Interfaces for your system, go to the Miscellaneous
Installation Considerations section on Page 35.
