Advanced Configuration Topics

Working with Display Tables

154

68-12286-110

To display the Display Table window, select View / Display Tables from the menu.

Display Table Properties Window

To display the overall properties for a Display Table, Double-Click on its tab at the top of the window.

From the Display Table window you can change the following items
for this Display Table:

-Display Table (tab) name
-Number of input bits
-Offline Text & Colors (displayed when a module is offline)
- Logging flag for the Off-Line state.
-Busy State indicator (for legacy modules)
