Advanced Configuration Topics Working with Display Tables
153 68-12286-110
Advanced Configuration Topics – MCN Config Server 8000
Working with Display Tables
Display Tables map the input bit values from the devices to the text and colors to be displayed on the
screen. If there is a standard Display Table for your receivers or I/O types, you probably will not need to
modify the data in the Display Tables window.
The Display Tables window allows you to:
•
Define new Display Tables for I/O devices and
•
Modify the text and colors displayed for the default Display Tables provided with the software.
A number of Display Tables are pre-defined for comparators:
• Comparator
for Astrotac, Digitac, Spectra-TAC, SNV-12, etc.
• GCM 8000, GCM LV
for GCM 8000 IP comparators
• MLC 8000, MLC LV, MLC Tech
(for MLC 8000 Analog Comparators
• Mixed Mode, MM LV, MM Tech
for Mixed Mode GCM 8000 & MLC 8000 Analog Comparator systems
• DIU
for Astrotac 3000 DIU ports
Other Display Tables are pre-defined of I/O purposes or system control:
• Main Standby
• Repeat
• Master and Sub-Comparator Display tables
• On-Off
• Generator
• Door
• Power
• Fail
• Temperature
• Binary
If you don't need to add or change any Display Tables, jump ahead to the Building Screens -- Display
Windows section on page 99 to start building display screens.
