Advanced Configuration Topics Working with Display Tables
156 68-12286-110
State Priority
The states in the table have the following priority:
1. Off-Line If the module is off-line.
2. Numbered States Lowest number has the highest priority.
3. Default State If no other state is found to match the input bits.
If an input value is covered by two defined states, the lower numbered state will be displayed.
State Text & Color Field
This is free-format text to be displayed when this state is active.
Foreground and background colors can be defined for each state.
Sound Field
This field is the .WAV sound file to be played if the input has the Alarm bit enabled. It will be
played whenever any input changes to this state.
Sounds are played only if the state is also logged. If you want a sound to play for a state entry,
make sure the Log field is set to 1.
Alarm Field
This is a flag to determine whether or not to show this bit in the Alarm window (and play a
sound associated with it) when it is active.
0 = Don't use Alarm Window
1 = Use Alarm Window
If the Alarm flag is set to 1, the input will appear in the Alarm Window (and an optional sound
will be played) whenever an input goes into this state.
Log Field
This is a flag to determine whether or not to log this state (to screen, printer, or disk).
0 = Don't log
1 = Log
If the Log flag is set to 1, a log entry will be generated whenever an input goes into or out of
this state.
