Appendix B
Appendix B Data Formats and I/O Ranges B-7
Range
Code
(hex)
Input Range
Description
Data Formats +F.S. Zero -F.S. Displayed
08 ± 10 mV
Engineering
Units
+10.000 ±00.000 -10.000 Resolution
% of FSR +100.00 ±000.00 -100.00 1 µv
Twos
Complement
7FFF 0000 8000 0.01%
09 ± 5 V
Engineering
Units
+5.0000 ±0.0000 -5.0000 1 LSB*
% of FSR +100.00 ±000.00 -100.00 100.00 µv
Twos
Complement
7FFF 0000 8000 0.01%
0A ± 1 V
Engineering
Units
+1.0000 ±0.0000 -1.000 1 LSB*
% of FSR +100.00 ±000.00 -100.00 100.00 µv
Twos
Complement
7FFF 0000 8000 0.01%
0B ± 500 mV
Engineering
Units
+500.00 ±000.00 -500.00 1 LSB*
% of FSR +100.00 ±000.00 -100.00 10 µv
Twos
Complement
7FFF 0000 8000 0.01%
0C ± 150 mV
Engineering
Units
+150.00 ±000.00 -150.00 1 LSB*
% of FSR +100.00 ±000.00 -100.00 10 µv
Twos
Complement
7FFF 0000 8000 0.01%
0D ± 20 mV
Engineering
Units
+20.000 ±00.000 -20.000 1 LSB*
% of FSR +100.00 ±000.00 -100.00 1 µv
Twos
Complement
7FFF 0000 8000 0.01%
Range
Code
(hex)
Input Range
Description
Data Formats
Maximum
Specitied
Signal Minimum
Specitied
Signal
Displayed
Resolution
0E
Type J
Thermocouple
0°C to 760°C
Engineering
Units
+760.000 +000.00 0.01°C
% of FSR +100.00 +000.00 0.01%
Twos
Complement
7FFF 0000 1 LSB*
