ADAM 4000 Series User’s Manual
4011, 4011D, 4012, 4016
@AADI
Status Code
DO0 001 002 003
OO
OFF OFF
OFF
OFF
O1
OFF OFF
OFF
ON
O2
OFF OFF
ON
OFF
O3
OFF OFF
ON
ON
O4
OFF ON
OFF
OFF
O5
OFF ON
OFF
ON
O6
OFF ON
ON
OFF
O7
OFF ON
ON
ON
O8
ON OFF
OFF
OFF
O9
ON OFF
OFF
ON
OA
ON OFF
ON
OFF
OB
ON OFF
ON
ON
OC
ON ON
OFF
OFF
OD
ON ON
OFF
ON
OE
ON ON
ON
OFF
OF
ON
ON
ON
ON
II
is a hexadecimal number representing the Digital input
port’s channel status (00h = D/I channel is Low, 01h =
channel is High).
(cr)
represents terminating character,
carriage return (0Dh).
Example command:
@15DI(cr)
response:
!510001(cr)
The analog input module at address 15h is instructed to
return digital I/O data and alarm status.
The module responds that both digital output channels are
OFF, digital input is HIGH, and alarm state is Momentary.
