Pulsar Plus Controller Family
Issue 7 December 2011
72
Alarm Thresholds
Table 16 Alarm Thresholds Status
Float Voltage Alarms Shows the configured settings for the Float Settings: Very High Major (HVSD),
High Minor, Battery on Discharge (BD) and Very Low Voltage (VLV) alarms.
Values are shown in (xx.xxV) format.
Boost Voltage
Alarms
Shows the configured settings for the Boost Settings: Very High Major (HVSD),
High Minor, and Battery on Discharge (BD) alarms. Values are shown in (xx.xxV)
format.
High Batt Temp
Shows measured value of the highest battery temperature of all attached
QS873 battery thermal probes.
Reserve Low
Shows configured value for the Low battery reserve time alarm.
High Ambient Temp
Shows configured value for the High Ambient Temperature alarm. This
temperature is from the temperature sensor located on the controller itself.
Low Ambient Temp
Shows configured value for the Low Ambient Temperature alarm. This
temperature is from the temperature sensor located on the controller itself.
Enabled/Disabled Info
This section of the menu provides a location to determine the Enable/Disable status of most controller
features.
Table 17 Enabled/Disabled Info Status
Temp Comp
Shows whether Battery Temperature Compensation is Enabled or Disabled.
Low Temp Comp
Shows if the Low Temperature compensation features is Enabled or Disabled.
Note: General temperature compensation must be Enabled to use Low
Temperature compensation.
Recharge Ilim
Shows if the Recharge Current Limit feature is Enabled or Disabled.
Emrgncy Pwr Off
Displays whether or not the Emergency Power Off (Remote Emergency Battery
Disconnect) feature is Enabled or Disabled. If Enabled, EPO is asserted when
contact closure is applied to the EPO input. The controller will keep battery
contactors open until this contact closure has been removed. The feature
assumes that AC has been removed to the system.
Critical=Major
Shows if the assertion of the Critical alarm severity with all Major alarms
feature is Enabled or Disabled.
ACO
Shows if Audible Alarm Cut-off feature is Enabled or Disabled.
Local Buzzer
Shows if the on-board local audible buzzer is Enabled or Disabled.
Alarm Test
Shows if the Form-C Alarm Test Feature is Enabled or Disabled.
Auto Boost
Shows if the automatic boost charge mode of operation is Enabled or Disabled.
Auto Batt Test
Shows if the automatic battery test feature is Enabled or Disabled.
Rect Redundancy
Shows if the Rectifier redundancy feature is Enabled or Disabled.
Mid-Cell V Mon
Shows if the Mid-String Voltage imbalance detection feature is Enabled or
Disabled.
Imminent Shutdn
Shows if the Imminent system shutdown alarm (LVBD) feature is Enabled or
Disabled.
