Pulsar Plus Controller Family
Issue 7 December 2011 142
Table 47 T1.317 User Login Related commands
obj,attr Description sta cha ope type Range of Values
x,ide Identifier  text USR01-USR14, ADM1
x,des Description   text User Account 1-14
Administrator Account
x,pwd Password   text 15 characters
x,usr User name   text 15 characters
x,lvl Security level   text “USER”, “SUPER-USER”,
“ADMINISTRATOR”
Table 48 T1.317 DC Plant Related Commands
obj,attr description sta cha ope type Range of Values
dc1,ide Description  text DC1
dc1,des Description   text DC Plant 1
dc1,typ Plant Type    number 48V, 24V
dc1,vdc Plant voltage   number dd.dd V
dc1,adc Plant load current   number ddd.d A
dc1,cap Total installed rectifier capacity  number ddd.d A
dc1,olcap Total on-line rectifier capacity  number ddd.d A
dc1,trd Plant total rectifier drain  number ddd.d A
dc1,sht Centralized plant shunt type   Text “NONE”, ”BATTERY”, ”LOAD”
dc1,sha Centralized plant shunt size   Number 0=disabled 1-9999
dc1,stt Plant state   text “FLOAT”, “BOOST”
dc1,bod Battery on discharge  number 0=on discharge 1=not on
discharge
dc1,rss Rectifier restart   number 0=no action 1=restart
dc1,rsq Rectifier sequencing   number 0=disable 1=enable
dc1,ron User Group TR request   Number 0-3 LSB = User, MSB=PBT
dc1,rot All Rectifier On Threshold   number 20-25or 40-50 volts
dc1,nst Number of battery strings   number 1-70
dc1,cps Number of Cells per String   number 1-75 (24V plant) or 24 (48V plant)
dc1,bty Battery type    Text See battery type definitions
default (OPE causes battery
defaults to be loaded)
dc1,isd Imminent shutdown enable   number 0=disable 1=enable
dc1,rtm Actual reserve time  text Low Current-Batt current too low
High Current-Batt current too high
dd.d (in hours)
dc1,scap String capacity   number
dc1,mls All load shunts monitored   number 0=disable 1=enable
Table 49 T1.317 Alarms With Two Thresholds Related Command
obj,attr Description sta cha ope type Range of Values
objid,ide Identifier  text see below
objid,des Description   text see below
objid,fds Front Panel Description   text see below
objid,ast Alarm state  number 0=not active 1=active
objid,led LED   text BD,AC,DC,””
objid,sev Alarm severity   text CRIT, MAJ, MIN, WRN, RO
objid,fth Alarm boost threshold   number see below
objid,bth Alarm float threshold   number see below
