GE Industrial Solutions Pulsar Plus Controller User Manual
Page 41
Pulsar Plus Controller Family
Issue 7 December 2011
41
Connect to the Controller
Step
Action
Once connected the CP communication will resembled that depicted below.
The RJ45 communication bracket must not interfere or be interfered with by the multi-shelf cable
interconnections. Ribbon cable assembly 848738253 must be used to connect from J2 of the first
CP shelf to J1 on the second CP shelf as shown.
Ground Screw
