Pulsar Plus Controller Family
Issue 7 December 2011 174
Table D-1 Standard Configuration Item Defaults
Factory Default
Factory 24V
Rectifier
Default
Factory 48V
Rectifier
Default
Category Description Range Factory Factory 24V Factory 48V obj,attr
Contactor Interfaces
ID1 Type
None/CN1/
CN2/CN3/CN4
"CN1" DCN01,TYP
ID2 Type
None/CN1/
CN2/CN3/CN4
"CN2" DCN02,TYP
ID3 Type
None/CN1/
CN2/CN3/CN4
"CN3" DCN03,TYP
ID4 Type
None/CN1/
CN2/CN3/CN4
"CN4" DCN04,TYP
ID5 Type
None/CN1/
CN2/CN3/CN4
"None" DCN05,TYP
ID6 Type
None/CN1/
CN2/CN3/CN4
"None" DCN06,TYP
ID7 Type
None/CN1/
CN2/CN3/CN4
"None" DCN07,TYP
ID8 Type
None/CN1/
CN2/CN3/CN4
"None" DCN08,TYP
Imminent LVBD Shutdown
1=Enabled
0=Disabled
0 DC1,ISD
Rectifiers
Rectifier Redundancy Loss Enable
1=Enabled
0=Disabled
0 GM1,RME
Rectifier Loadshare Enable
1=Enabled
0=Disabled
1 GM1,LSE
Rectifier Float Current Limit 30 to 100% 100 GM1,FCL
Rectifier Boost Current Limit 30 to 100% 100 GM1,BCL
Group Standby/Sequencing Enable
1=Enabled
0=Disabled
0 DC1,RSQ
Remote rectifier Off Enable
1=Enabled
0=Disabled
0 PS1,RRF
Rectifier Redundancy Threshold 1 to 80 1 RLS1,THR
Multiple Rectifier Fail 2 to 88 2 MFA1,THR
Oring FET test enable
1=Enabled
0=Disabled
1 GM1.OFT
Efficiency Enable
1=Enabled
0=Disabled
1 DC!,EME
Efficiency Target 20% to 95% 70 DC1,EMT
Efficiency Rectifier Turn On
Threshold
25% to 100% 76 DC1,EMO
Converters Converter Internal Selective High
Output Voltage Shutdown 25.0 to 30.0V50.0 to
60.0V 58.0 29.0 CP1,VSD
High Output Voltage Major Alarm
25.0 to 30.0V
50.0 to 60.0V
56.0 28.5 CHVA1, THR
High Output Voltage Minor Alarm
24.0 to 30.0V
48.0 to 60.0V
54.0 27.0 CHFV1,THR
Output Voltage Set-Point
23.0 to 27.2V
46.0 to 54.5V
52.0 26.0 CP1,VSP
Low Voltage Alarm
20.0 to 27.0V
40.0 to 54.0V
46.0 23.0 CVLA1,THR
Converter Current Limit 30 to 100% 100 CP1,CLM
Converter Redundancy Loss Enable
1=Enabled
0=Disabled
0 CP1,RME
Remote converter Off Enable
1=Enabled
0=Disabled
0 CP1,ROF
Low Voltage Disconnect Input
Threshold 20.0 to 25.0V
40.0 to 50.0V
23.0 46.0 CP1,DTH
Low Voltage Reconnect Input
Threshold 22.0 to 27.0V
44.0 to 54.0V
25.0 50.0 CP1,RTH
Low Voltage Disconnect Enable
1=Enabled
0=Disabled
0 CP1,LVD
Converter Redundancy Threshold 1 to 32 1 CRL1,THR
Multiple Converter Fail 2 to 30 2 CMFA1,THR
Battery Type
Definitions Battery 1 Type Description <=32 chars
"Generic Valve-Reg
Battery" BT01,DES
Battery 1 Type "Valve-Reg" BT01,BTY
Battery 1 Class "VALVE-REG" BT01,BTC
Battery 1 Capacity 0 BT01,CAP
Battery 2 Type Description <=32 chars "Generic Flooded Battery" BT02,DES
