GE Industrial Solutions Pulsar Plus Controller User Manual
Page 33
Pulsar Plus Controller Family
Issue 7 December 2011
33
Connect to the Controller
Step
Action
4
Output Alarm Connector
All controller customer output alarm contacts are available at the J4 output connector interface.
J4 is a 20-pin right angle header with latching capability. Standard color coded alarm cable
assemblies are available. Part numbers for the 50’ and 150’ 24AWG solid twisted pair output
cables are CC848817635 and CC848817643, respectively. Contact technical field support for
additional cable options. Utilize the appropriate cable to obtain the desired connections to the
outputs shown below.
