Pulsar Plus Controller Family
Issue 7 December 2011 148
Table 56 T1.317 Battery Reserve Management Related Commands
obj,attr Description sta cha ope type Range of Values
br1,nvm Number of mid-cell V present  d
br1,ntm Number of temperatures present  d
br1,scd Battery voltage imbalance
detection enable  number 0=disable,1=enable
(Automatically enabled
when mid cell V monitor
present)
br1,scv Battery imbalance threshold   number 1.5-3.0V
Table 57 T1.317 Battery Type Definition Related Commands
obj,attr Description sta cha ope type Range of Values
btnn,des Description   Text Battery Configuration 1
btnn,bty Battery Type   Text Up to 14 characters
btnn,btc Battery Class   Text FLOODED, SEALED, NICD,
LI_LMP, LI_ELITE
btnn,cap Capacity   Number number
Where n stands for battery type number (1 thru 25)
Table 58 T1.317 Boost Management Related Commands
obj,attr Description sta cha ope type Range of Values
bs1,ide Identifier  Text BS1
bs1,des Description   Text Boost Control 1
bs1,stt State   Text QRCT, MANUAL, BTP, TIMED
AU-TO, OFF
bs1,atm Auto Mode   Text OFF, QRCT, TIMED
bs1,tmd Timed Manual Duration   Number 1-80 hours
bs1,amf Auto Multiplication Factor   Number 0.1-9
bs1,cta Current Term Current Thresh   Number 1-999A
Table 59 T1.317 Disconnect Contactor Control Related Commands
obj,attr Description sta cha ope type Range of Values
cnx,ide Identifier  number CN1, CN2, CN3, CN4
cnx,des Description   number Contactor 1
cnx,stt Status   text NONE, DISCON, CONNECT,
FAILED
cnx,ena Control enable   0=disable,1=enable
cnx,dth Disconnect threshold   number 19-25V or 39-50V
cnx,ddy Disconnect delay   number 0-300 minutes
cnx,dam Disconnect automode   text 0=“NONE”
1=“VOLTAGE”
2= “VOLTAGE+TIME”
cnx,dtm Disconnect remaining time  number >0 means going to
disconnect
cnx,rth Reconnect threshold   number 19.5-27V or 39-55V
cnx,rdy Reconnect delay   number 0-300 seconds
cnx,ram Reconnect automode   text 0=“NONE”
1=“VOLTAGE”
2=“VOLTAGE+TIME”
cnx 4,rtm Reconnect remaining time  number >0 means going to reconnect
The contactors are identified as follows:
