Pulsar Plus Controller Family
Issue 7 December 2011 178
Table D-1 Standard Configuration Item Defaults
Factory Default
Factory 24V
Rectifier
Default
Factory 48V
Rectifier
Default
Category Description Range Factory Factory 24V Factory 48V obj,attr
ID7 Type Battery/None /Load "NONE" DCM07,TYP
ID7 Shunt Current Rating 0 to 9999 Amps 600 DCM07,SHA
ID8 Type Battery/None /Load "NONE" DCM08,TYP
ID8 Shunt Current Rating 0 to 9999 Amps 600 DCM08,SHA
All Load Shunts Monitored
1=Enabled
0=Disabled
0 DC1,MLS
Built-in Inputs
Input 1 Description <=32 chars "Fuse Alarm Major 24V" IN001,DES
Input 1 Type "FAJ1" IN001,TYP
Input 1 Active State
CLOSED=Battery
OPEN=No BAT
"CLOSED" IN001,POL
Input 2 Description <=32 chars "Fuse Alarm Major 48V" IN002,DES
Input 2 Type "FAJ2" IN002,TYP
Input 2 Active State
CLOSED=Battery
OPEN=No BAT
"CLOSED" IN002,POL
Input 3 Description <=32 chars "Auxiliary Major Alarm" IN003,DES
Input 3 Type "AMJ1" IN003,TYP
Input 3 Active State
CLOSED=Battery
OPEN=No BAT
"CLOSED" IN003,POL
Input 4 Description <=32 chars "Open String" IN004,DES
Input 4 Type "OSA1" IN004,TYP
Input 4 Active State
CLOSED=Battery
OPEN=No BAT
"CLOSED" IN004,POL
Input 5 Description <=32 chars "Emergency Power Off" IN005,DES
Input 5 Type "REMLVD" IN005,TYP
Input 5 Active State
CLOSED=Closed to
RTN, OPEN=Open to
RTN
"CLOSED" IN005,POL
Input 6 Description <=32 chars "Group Standby/PBT" IN006,DES
Input 6 Type "" IN006,TYP
Input 6 Active State
CLOSED=Closed to
RTN, OPEN=Open to
RTN
"CLOSED" IN006,POL
Input 7 Description <=32 chars "Air Conditioner Fail" IN007,DES
Input 7 Type "AUX1" IN007,TYP
Input 7 Active State
CLOSED=Closed to
RTN, OPEN=Open to
RTN
"CLOSED" IN007,POL
Input 8 Description <=32 chars "Door Open" IN008,DES
Input 8 Type "AUX2" IN008,TYP
Input 8 Active State
CLOSED=Closed to
RTN, OPEN=Open to
RTN
"CLOSED" IN008,POL
Input 9 Description <=32 chars "High External Ambient" IN009,DES
Input 9 Type "AUX3" IN009,TYP
Input 9 Active State
CLOSED=Closed to
RTN, OPEN=Open to
RTN
"CLOSED" IN009,POL
Input 10 Description <=32 chars "Low External Ambient" IN010,DES
Input 10 Type "AUX4" IN010,TYP
Input 10 Active State
CLOSED=Closed to
RTN, OPEN=Open to
RTN
"CLOSED" IN010,POL
