Pulsar Plus Controller Family
Issue 7 December 2011 154
Table 75 T1.317 Trend Related Commands
obj,attr Description sta cha ope type Range of Values
Obj,ide Identifier  DCT1 for DC plant load
CPT1 for DC converter load
dct1,des Description   Text DC1 Trend Statistics
CP1 Trend Statistics
dct1,src Source   Text DC1 ADC
CP1 ADC
Table 76 T1.317 TL1 Manager Related commands
obj,attr Description sta cha ope type range
tlm1,des Description   text 30 char (TL1 Manager)
tlm1,aue Activate-User Enable   number 0=disable 1=enable
tlm1,cts CTS Connect Detection   number 0=disable 1=enable
tlm1,dsr DSR Connect Detection   number 0=disable 1=enable
Tlm1,prt Port   number 2020
Tlm1,tmo Timeout   number 0-60 minutes
Table 77 T1.317 TL1 Object Related Commands
obj,attr Description sta cha ope type Range of Values
tln,des Description   text 30 char (TL1 Object n)
tln,cds Condition Description   text 60 char
tln,aid Aid   text 20 char
tln,cnd Condition Type   text 20 char
tln,saf Service Affecting   Number 0=no 1=yes
tln,rpt Reporting   text EQUIPMENT,
ENVIRONMENT, PRESENCE
Where n is the TL object number from 001 thru 256 128
Table 78 T1.317 Call-Back Security Related Commands
obj,attr Description sta cha Ope type Range of Values
cb1,des Description   text Call-Back Security 1
cb1,stt State   number 0=off 1=on
cb1,ph1-5 Call-Back Phone Number   Text Digit () * # - , space
cb1,br1-5 Connect Baudrate   number 300, 1200, 2400, 4800, 9600,
14400
Table 79 T1.317 Mid-String Voltage Related Commands
obj,attr Description sta cha ope type Range of Values
msnc,des Description   text 30 char (Mid-String Voltage
Module n Channel c)
msnc,stt State   text None, Present, Missing
msnc,val Value  Number Mid-String voltage
msnc,did Duplicate Id  Number 0=no 1=yes
Where n is the Mid-String module number from 1 to 7, and
c is the Mid-String channel number form 1 to 3
