Pulsar Plus Controller Family
Issue 7 December 2011 145
obj Description
faj2 External 48V Fuse Major
fan1 External 24V Fuse Minor
fan2 External 48V Fuse Minor
hcl1 History Cleared
icc1 Incompatible Converter
icr1 Incompatible Rectifier
isd1 Imminent shutdown
man1 Manual Off
mcm1 Major Communications Fail
mdp1 Voltage Duplicate Id
mzd1 Voltage Id Not Configured
nnc1 Number Not Configured
osa1 Open String
pfd1 Password At Default
pgi1 Program Line Invalid
pht1 Processor Halt
por1 Number Did Not Respond
rcdp1 Ringer ID Conflict
rf1 Ringer fail
rfa1 Rectifier Fail
rfn1 Rectifier fan fail
rpff1 Ringer fan fail
rpfj1 Ringer fail major
rprl1 Ringer redundancy loss
rpxj1 Ringer 1 major external fault
rpxn1 Ringer 1 minor external fault
scd1 Battery voltage imbalance
stf1 Self Test Failed
tpa1 Thermal probe fail
vmf1 Voltage module fail
vsf1 Sense/Control Fuse
zid1 ID Not Configured
Table 52 T1.317 Rectifier Management Related Commands
obj,attr Description sta cha ope type Range of Values
gm1,ide Identifier  Text GM1
gm1,des Description   Text Rectifier Manager 1
gm1,lse Load Share Enable   number 0=disable 1=enable
gm1,rme Redundancy monitor enable   number 0=disable,1=enable
gm1,fsd Float High Voltage Shutdown   number 25-30 or 50-60 V
gm1,bsd Boost High Voltage Shutdown   number 26-30 or 52-60 V
gm1,fsp Float Set-Point   number 22-28 or 44-56.5 V
gm1,bsp Boost Set-Point   number 22-30 or 48-60 V
gm1,fcl Float Current Limit   number 30-110%
gm1,bcl Boost Current Limit   number 30-110%
Table 53 T1.317 Rectifiers Related Commands
obj,attr Description sta cha ope type Range of Values
gsr,des Description   text Rectifier sr
gsr,typ Rectifier Type   text 12 char
gsr,sn Serial number  text Up to 18 characters
