Pulsar Plus Controller Family
Issue 7 December 2011 149
CN1 = Battery Disconnect (LVBD1)
CN2 = Load 1 Disconnect (LVLD1)
CN3 = Load 2 Disconnect (LVLD2)
CN4 = Load 3 Disconnect (LVLD3)
Table 60 T1.317 Distribution Current Monitor Related Commands
obj,attr Description sta cha ope type Range of Values
dcmxx,ide Identifier  number DCMC1 is the plant shunt
DCM01-DCM08
dcmxx,des Description   number Contactor 1
dcmxx,stt State  text NONE
MISSING
PRESENT
dcmxx,typ Shunt Type   text NONE
LOAD
BATTERY
dcmxx,val Reading  number ddd.d Amps
dcmxx,sha Shunt amp rating   number 0-9999 Amps
The shunt type defaults are as follows:
DCMC1 = Battery
DCM01 = Battery
DCM02-DCM08 = Load
Table 61 T1.317 Distribution Contactor Interface Related Commands
obj,attr Description sta cha ope type Range of Values
dcnxx,ide Identifier  number DCN01-DCN06
dcnxx,des Description   number Contactor 1
dcnxx,stt State  text NONE
MISSING
OPEN
CLOSED
dcnxx,typ Contactor interface type   text NONE, CN1, CN2, CN3, or
CN4
The contactor interface type defaults are as follows:
DCN01 = CN1
DCN02 = CN2
DCN03 = CN3
DCN04-DCN08 = CN4
Table 62 T1.317 Slope Thermal Compensation Related Commands
obj,attr Description sta cha ope type Range of Values
sc1,ide Identifier  Text SC1
sc1,des Description   Text Slope Thermal Comp
sc1,stt State   number 0=disable 1=enable
sc1,rve Raise Voltage Enable   number 0=disable 1=enable
sc1,ltt Lower Temperature Threshold   number -5-20°C or 23-68°F
sc1,ntt Nominal Temperature Threshold   number 15-30°C or 59-86°F
sc1,utt Upper Temperature Threshold   number 30-55°C or 86-131°F
sc1,spt Step Temperature   number 45-85°C or 113-185°F
sc1,lsp Low temperature slope   number 1-10mV/°C per cell
sc1,usp Upper temperature slope   number 1-10mV/°C per cell
