Table D-1 Standard Configuration Item Defaults
Factory Default
Factory 24V
Rectifier
Default
Factory 48V
Rectifier
Default
Category
Description
Range
Factory
Factory 24V
Factory 48V
obj,attr
Auxiliary Alarms
Auxiliary Alarm 1 Description
<=32 chars
"Air Conditioner Fail"
AUX1,DES
Auxiliary Alarm 1 Front Panel Desc
<=24 chars
"Air Conditioner Fail"
AUX1,FDS
Auxiliary Alarm 2 Description
<=32 chars
"Door Open"
AUX2,DES
Auxiliary Alarm 2 Front Panel Desc
<=24 chars
"Door Open"
AUX2,FDS
Auxiliary Alarm 3 Description
<=32 chars
"High External Ambient"
AUX3,DES
Auxiliary Alarm 3 Front Panel Desc
<=24 chars
"High External Ambient"
AUX3,FDS
Auxiliary Alarm 4 Description
<=32 chars
"Low External Ambient"
AUX4,DES
Auxiliary Alarm 4 Front Panel Desc
<=24 chars
"Low External Ambient"
AUX4,FDS
Auxiliary Alarm 5 Description
<=32 chars
"Fan Fail"
AUX5,DES
Auxiliary Alarm 5 Front Panel Desc
<=24 chars
"Fan Fail"
AUX5,FDS
Auxiliary Alarm 6 Description
<=32 chars
"Hydrogen Present"
AUX6,DES
Auxiliary Alarm 6 Front Panel Desc
<=24 chars
"Hydrogen Present"
AUX6,FDS
Ringers
Ringer Output Voltage Set-Point
65-100 VAC
100
RP1,VSP
Ringer Output Frequency
15-50Hz
20
RP1,FRQ
Ringer DC Output Offset Feature
1=Enabled/
0=Disabled
1
RP1,OFE
Ringer Redundancy Loss Feature
1=Enabled/
0=Disabled
1
RP1,RME
Alarm Test
Alarm Test Enable
1=Enabled
0=Disabled
1
AT1,LTE
Duration of Each Relay Closure
5 to 300 sec
30
AT1,DUR
PCR Relay Test Enable
1=Enabled
0=Disabled
1
AT1,PCR
PMJ Relay Test Enable
1=Enabled
0=Disabled
1
AT1,PMJ
PMN Relay Test Enable
1=Enabled
0=Disabled
1
AT1,PMN
R1 Relay Test Enable
1=Enabled
0=Disabled
1
AT1,R1
R2 Relay Test Enable
1=Enabled0=Disabled
1
AT1,R2
R3 Relay Test Enable
1=Enabled
0=Disabled
1
AT1,R3
R4 Relay Test Enable
1=Enabled
0=Disabled
1
AT1,R4
R5 Relay Test Enable
1=Enabled
0=Disabled
1
AT1,R5
R6 Relay Test Enable
1=Enabled
0=Disabled
1
AT1,R6
R7 Relay Test Enable
1=Enabled
0=Disabled
1
AT1,R7
Buzzer Test Interval
5-300sec
10
AT1,BZI
Alarm Cut-Off
Critical Alarm Cut-off Enable
1=Enabled
0=Disabled
1
ACO1,CAE
Critical Alarm Cut-off Timeout
1 to 4 hours
1
ACO1,CTO
Major Alarm Cut-off Enable
1=Enabled
0=Disabled
1
ACO1,JAE
Major Alarm Cut-off Timeout
1 to 4 hours
1
ACO1,JTO
Minor Alarm Cut-off Enable
1=Enabled
0=Disabled
1
ACO1,NAE
Minor Alarm Cut-off Timeout
1 to 72 hours
8
ACO1,NTO
Local Buzzer Enable
1=Enabled
0=Disabled
1
ACO1,LBE
Communication
Ports
Communication Port Type
LOCAL or
MODEM
"LOCAL"
PS1,PTT
Local Port Write Access
1=Enabled
0=Disabled
1
LP1,WRE
Local RS-232 baud rate
2400/4800/ 9600/
Auto
"AUTO"
LP1,BDR
