Pulsar Plus Controller Family
Issue 7 December 2011 184
Table D-3 48V Battery Related Items Defaults
Category Description Range Valve-Reg Flooded Li_ELiTE NiCd Li-LMP obj,attr
Voltage Settings Rectifier Float Selective High Voltage
Shutdown
-50 to -60V 58.50 58.50 58.50 58.50 58.50 GM1,FSD
High Float Voltage Major Alarm -50 to -60V 57.00 57.00 57.00 57.00 57.00 HVA1,FTH
High Float Voltage Minor Alarm -50 to -60V 56.00 56.00 56.00 56.00 56.00 HFV1,FTH
Rectifier/System Float Voltage -42 to -56.5V 54.48 52.08 54.48 54.40 54.48 GM1,FSP
Battery on Discharge Float Alarm -46 to -55V 51.00 50.00 53.00 51.00 51.00 BDA1,FTH
Very Low Float Voltage Alarm -40 to -51V 46.00 46.00 46.00 46.00 46.00 VLA1,THR
Rectifier On Threshold -40 to -51V 44.00 44.00 44.00 44.00 44.00 DC1,ROT
Battery Disconnect
LV Battery Disconnect
1=Enabled
0=Disabled
1 1 0 1 0 CN1,ENA
LV Battery Disconnect Voltage -39.0 to -50V 42.00 42.00 42.00 42.00 42.00 CN1,DTH
LV Battery Reconnect Voltage -39.0 to -55V 48.00 48.00 48.00 48.00 48.00 CN1,RTH
Batteries
Cells Per String 0 to 75 24 24 24 24 24 DC1,CPS
String End Of Discharge Voltage
-40.25 to -
48.75V
42.00 42.00 42.00 42.00 42.00 BR1,CEV
Recharge Current Limit Feature
1=Enabled
0=Disabled
0 0 0 0 0 BR1,CLE
Recharge Current Limit Value 5 to 1000A 50 50 25 25 25 BR1,CLT
Boost Maximum Duration 1 to 80 Hours 1 1 1 1 1 BS1,TMD
Voltage Imbalance Detect 1.5V to 3.0V 1.7 1.7 1.7 2.0 1.7 BR1,SCV
High Temperature Battery Disconnect 30 to 90 o C 75 75 75 75 75 BR1,TTH
High Battery Temperature 30 to 85 o C 55 55 55 55 85 BTHA1,THR
Battery Slope
Compensation
Slope Thermal Compensation (STC)
1=Enabled
0=Disabled
1 0 0 0 0 SC1,STT
High Temperature Voltage Step Down 45 to 85 o C 75 75 75 75 75 SC1,SPT
High Temperature Compensation Stop 30 to 55 o C 55 55 55 55 55 SC1,UTT
High Temperature Decrease Rate
1-10mV/ o C per
cell
3 3 3 3 3 SC1,USP
Nominal Temperature (No Temp Comp) 15 to 30 o C 25 25 25 25 25 SC1,NTT
Low Temperature Compensation Feature
1=Enabled
0=Disabled
0 0 0 0 0 SC1,RVE
Low Temperature Compensation Stop -5 to 20 o C 0 0 0 0 0 SC1,LTT
Low Temperature Decrease Rate
1-10mV/ o C per
cell
3 3 3 3 3 SC1,LSP
Battery Discharge Test
Timed Test Alarm Voltage Threshold -36 to -48V 44.00 44.00 46.00 44.00 44.00 BR1,TEV
Rectifier Voltage During Battery Test -42.00 to -52V 42.00 42.00 42.00 42.00 42.00 BR1,BTV
Battery Boost
Boost Rectifier High Voltage Shutdown -52 to -60V 58.50 58.50 58.50 58.50 58.50 GM1,BSD
Boost High Voltage Major Alarm -50 to -60V 57.0 58.5 57.0 57.0 57.0 HVA1,BTH
Boost High Voltage Minor Alarm -50 to -60V 56.0 58.0 56.0 56.0 56.0 HFV1,BTH
Boost Voltage -48 to -58V 55.2 57.0 54.5 54.4 54.5 GM1,BSP
Boost Battery on Discharge Alarm -46 to -55V 51.0 50.0 53.0 51.0 51.0 BDA1,BTH
