GE Industrial Solutions Pulsar Plus Controller - Manual (Page 188)

Pulsar Plus Controller Family
Issue 7 December 2011 188
Table E-2 Alarms, Alarm Relays and LEDs Assignments – Phoenix Display
Severity - Relay and Display Additional Relay LED
Description CRIT PMJ PMN WRN RO R1 R2 R3 R4 R5 R6 R7
Object
ID
Auxiliary 6 MAJ AUX6
Auxiliary 7 MAJ AUX7
Auxiliary 8 MAJ AUX8
Auxiliary 9 MAJ AUX9
Auxiliary 10 MAJ AUX10
Auxiliary 11 MAJ AUX11
Auxiliary 12 MAJ AUX12
Auxiliary Major Alarm MAJ R3 DFA AMJ1
Battery Test Active RO R2 BOD BTA1
Battery on Discharge (Float and Boost) MAJ R2 BOD BDA1
Check Battery MIN BFA1
Real Time Clock Battery Low MIN BBL1
Clock Changed RO CLC1
Communication Loss Major MAJ MCM1
Communication Loss Minor MIN CMA1
Configuration Changed RO CCH1
Controller Ambient Temperature High MIN TEMP AMTH1
Controller Ambient Temperature Low MIN TEMP AMTL1
Controller Fail (Not user mappable) x x x
Converter Distribution Fuse MAJ R3 DFA CDFA1
Converter Fail MAJ R7 CFA CFA1
Converter Fan Minor MIN R7 CFA CFN1
Converter Low Voltage CRIT R7 CFA CVLA1
Converter High Voltage Major MAJ R7 CFA CHVA1
Converter High Voltage Minor MIN R7 CFA CHFV1
Converter ID Conflict MAJ R7 CDID1
Converter Redundancy Loss MAJ R7 CFA CRL1
Defective Temp Probe MIN TPA1
Emergency Power Off (EPO) MAJ EPO1
Energy Management Disabled WRN EMD1
Excessive Login Attempts WRN EXL1
External Password Reset WRN EPR1
Fuse Major 24 MAJ R3 DFA FAJ1
Fuse Major 48 MAJ R3 DFA FAJ2
Fuse Minor 24 MIN R3 DFA FAN1
Fuse Minor 48 MIN R3 DFA FAN2
Generator Requires Maintenance MAJ GNM1
Generator Running MIN GNR1
High Battery Thermal alarm MIN BAT BTHA1
High Voltage Major MAJ R4 HVSD HVA1
High Voltage Minor MIN R4 HVA HFV1
History Cleared RO HCL1
ID Conflict MAJ DID1
ID Not Configured MAJ ZID1
Imminent LVBD Shutdown MAJ ISD1
