Pulsar Plus Controller Family
Issue 7 December 2011 123
Specifications
Table 45 Specifications
General Specifications
Item Specification
Input Voltage Ranges (power)
+/-24 volts: from +/-18 volts to +/-30 volts;
-48 volts: from -36.5 volts to -60 volts SELV
Input Power 6.0 watts maximum
Input Power Connections
NE843A/CP843A/EP843D, No external connection required;
NE843C/NE843E/NE843G/NE843P, (J9)12-pin connector
Bonding Network
Suitable for installation as part of either
• Common Bonding Network (CBN)
• an Isolated Bonding Network (IBN)
Facilities
Suitable for installation in
• Network Telecommunication Facilities
• Locations where the NEC applies
DC Return
• Isolated DC Return (DC-I) or
• Common DC Return (DC-C)
Front Panel User Interface
• 4 or 8-line by 40-character LCD
• Severity sensitive backlit LCD
(LEDs on NE 843P);
• Three status LEDs (20 on NE843P)
• Voltage test jacks;
• Six Push Buttons
(Rotary Control + 2 Push Buttons on NE843P)
System Configuration Methods
• Front panel LCD display and menu keys
(J5) and (J8) 10/100 Base-T port/s
(J7) DB9 for RS-232 port: T1.317 or EasyView
(J6) RJ11 for phone line connection –MODEM option
Maximum Power Units
• 60 NE Power Units
• 32 CP Power Units
Low-Voltage Disconnects
Manage up to eight LVD contactors using up to 3 independent
configurable Load disconnect thresholds (LVLDs) and 1 configurable
Battery disconnect threshold (LVBD).
Temperature Monitoring
Up to 16 One-Wire Battery Temperatures;
One on-board internal ambient temperature
