Pulsar Plus Controller Family
Issue 7 December 2011 186
Table E-1 Alarms, Alarm Relays and LEDs Assignments – Pulsar Display
Severity - Relay and Display Additional Relay LED
Description CRIT PMJ PMN WRN RO R1 R2 R3 R4 R5 R6 R7 AC DC BD
Object
ID
Controller Ambient Temperature High MIN AMTH1
Controller Ambient Temperature Low MIN AMTL1
Controller Fail (Not user mappable) x x x
Converter Distribution Fuse MAJ DC CDFA1
Converter Fail MIN R5 CFA1
Converter Fan Major MAJ R5 CFJ1
Converter Fan Minor MIN R5 CFN1
Converter Low Voltage CRIT R2 CVLA1
Converter High Voltage Major MAJ R7 CHVA1
Converter High Voltage Minor MIN R7 CHFV1
Converter ID Conflict MAJ CDID1
Converter Redundancy Loss MIN R5 CRL1
Defective Temp Probe MIN TPA1
Emergency Power Off (EPO) MAJ EPO1
Energy Management Disabled WRN EMD1
Excessive Login Attempts WRN EXL1
External Password Reset WRN EPR1
Fuse Major 24 MAJ R3 DC FAJ1
Fuse Major 48 MAJ R3 DC FAJ2
Fuse Minor 24 MIN R3 DC FAN1
Fuse Minor 48 MIN R3 DC FAN2
Generator Requires Maintenance MAJ GNM1
Generator Running MIN GNR1
High Voltage Major MAJ R7 HVA1
High Voltage Minor MIN R7 HFV1
History Cleared RO HCL1
ID Conflict MAJ DID1
ID Not Configured MAJ ZID1
Imminent LVBD Shutdown MAJ DC ISD1
Incompatible Converter MIN ICC1
Incompatible Rectifier MIN ICR1
Low Battery Temperature RO BTLA1
LV Disconnect Contactor 1 Fail MAJ CNF1
LV Disconnect Contactor 1 Open MAJ DC CNO1
LV Disconnect Contactor 2 Fail MAJ CNF2
LV Disconnect Contactor 2 Open MAJ CNO2
LV Disconnect Contactor 3 Fail MAJ CNF3
LV Disconnect Contactor 3 Open MAJ CNO3
LV Disconnect Contactor 4 Fail MAJ CNF4
LV Disconnect Contactor 4 Open MAJ CNO4
Manual Off MIN R5 MAN1
Multiple AC Fail MAJ R6 AC MACF1
Multiple Converter Fail MAJ R6 CMFA1
Multiple Manual Off MAJ R6 MMAN1
Multiple Rectifier Fail MAJ R6 MFA1
No Call-Out Response WRN COR1
