Pulsar Plus Controller Family
Issue 7 December 2011 147
Table 55 T1.317 DC Converter Related Commands
obj,attr Description sta cha ope type Range of Values
csr,des Description   Text DC Converter sr
csr,typ Type  Text 10 chars
csr,sn Serial number  Text Serial number
csr,adc DC Current  Number Number in amps
csr,cap Capacity  Number Number in amps
csr,stt State   Text ON*, OFF, STANDBY*,
MISSING, VACANT*
ON qualifiers –LIM
OFF qualifiers –LVD, -INF, -
TA, -HVSD, -FAN
csr,cfa Converter Fail  Number 0=inactive 1=active
csr,did ID Conflict  Number 0=inactive 1=active
csr,ccf Communication Fail  Number 0=inactive 1=active
s stands for shelf number (0 or 1)
r stands for converter number (1 thru 6)
* The user may only set the state to ON, STANDBY, or VACANT
Table 56 T1.317 Battery Reserve Management Related Commands
obj,attr Description sta cha ope type Range of Values
br1,des Description   Text Battery Reserve 1
br1,adc Total battery current  number d A (+ for discharge, - for
charge)
br1,hbt Highest battery temperature  number dd °C
br1,cap Installed battery capacity  number ddddd AH
br1,olcap On-line battery capacity  number ddddd AH
br1,btr Discharge test results  result,reserve,load text
result is one of the following:
COMPLETED
CHECK BATTERY
INTERRUPTED
ACTIVE
NOT RUN
reserve is hours calculate by
last complete test
load is load at beginning of
test
br1,tth High Temperature Threshold   Number 30-90 ° C or 86-194 ° C
br1,cle Current Limit Enable   number 0=disable 1=enable
br1,clt Current Limit Threshold   number 5-1000A
br1,cev Battery string end of discharge V   Number 19.25-22.75V
or 40.25-43.75V
br1,bts Battery Test State   number 0=inactive 1=active
br1,mtt Manual test type   text DISABLED, 20%, TIMED
br1,tev Manual test alarm voltage   number 21-27V or 36-48 V
br1,tmd Manual test duration   number 0.1-99.9 hours
br1,bte Auto test type   text DISABLED, 20%, TIMED
br1,btv Battery test rectifier voltage   number 21-26 V or 42-52 V
br1,ath Auto test start hour   number 0-23
br1,tin Auto test interval   number 1-18 months
br1,atw Auto test min hours after BD   number 0-240 hours
br1,atd Auto test date   date dd-mmm-yy
