Pulsar Plus Controller Family
Issue 7 December 2011 153
Table 71 T1.317 Alarm Test Related Commands
obj,attr Description sta cha ope type Range of Values
buzzer
at1,irt Individual Relay Test State   Number “”=Stop Test,
PCR,PMJ,PMN,R1,R2,R3,R4,R
5,R6,R7
Table 72 T1.317 Alarm Cut-off Related Commands
obj,attr Description sta cha ope type Range of Values
aco1,des Description   Text Alarm Cut-off 1
aco1,stt Alarm Cut-off State   Number 0=inactive 1=active
aco1,cst Critical Alarm Cut-off State  Number 0=inactive 1=active
aco1,cae Critical Alarm Cut-off Enable   Number 0=disable 1=enable
aco1,cto Critical Alarm Cut-off Time-Out   Number 1 to 8 hours
aco1,jst Major Alarm Cut-off State  Number 0=inactive 1=active
aco1,jae Major Alarm Cut-off Enable   Number 0=disable 1=enable
aco1,jto Major Alarm Cut-off Time-Out   Number 1 to 8 hours
aco1,nst Minor Alarm Cut-off State  Number 0=inactive 1=active
aco1,nae Minor Alarm Cut-off Enable   Number 0=disable 1=enable
aco1,nto Minor Alarm Cut-off Time-Out   Number 1 to 72 hours
aco1,lbe Local Buzzer Enable   Number 0=disable 1=enable
Table 73 T1.317 User Defined Events Related Commands
obj,attr Description sta cha ope type Range of Values
unnnn,des Description   Text 30 char
unnnn,fds Front Panel Description   text see below
unnnn,ast Alarm State  Number 0=inactive 1=active
unnnn,sev Severity   Text CRIT, MAJ, MIN, WRN, RO
unnnn,prg Program Line   Text 60 char
unnnn,dur Minimum Duration   Number > 0 seconds
unnnn,lat Latched   Number 0=no 1=yes
unnnn,led LED   text BD,AC,DC,””
unnnn,acc Contact Closure   text R1,R2,R3,R4,R5,R6,R7,””
unnnn,dly Notify Delay   Number 0-540 seconds
unnnn,no
o Notify On Occur   Number 0=no 1=yes
unnnn,nor Notify On Retire   Number 0=no 1=yes
unnnn,nag NAG On Occur   Number 0=no 1=yes
unnnn,dst Notify Destination   text “”, P1, P2, P3, P4, E1, E2, E3,
E4, S1, S2, S3, S4
where nnnn = 1 thru 128
Table 74 T1.317 Derived Channels Related Commands
obj,attr Description sta cha ope type Range of Values
DRnn,des Description   Text 30 char (Derived Chan nn)
DRnn,val Value  Number Number units
DRnn,prg Program line   Text 60 char
DRnn,uni Unit   Text 5 chars
Where nn is from 01 thru 8
