Pulsar Plus Controller Family
Issue 7 December 2011 27
Install and Configure Pulsar Plus NE843G Controller
Step Action
Jumper
Number
Signal
Name
Table 3 Table 2 Controller Standard Defaults NE843G
1 PCR Power Critical Alarm severity indicator
2 PMJ Power Major Alarm severity indicator
3 PMN Power Minor Alarm severity indicator
4 R1
Battery on Discharge alarm
(BD)
5 R2 AC and Multiple AC Fail alarm (ACF/MACF)
6 R3
Rectifier/Converter Fail alarm
(RFA/MRFA/CFA/MCFA)
7 R4
Very Low Voltage alarm
(VLV)
8 R5
Fuse Alarm - 48V
(External FAJ2/FAN2)
9 R6
High Voltage alarm
(HV)
10 R7
Fuse Alarm - 24V
(External FAJ1/FAN1)
8 If your system using optional ES771 Mid-String Voltage Modules continue. Otherwise go to
step 10.
