Table 37 QS871 J1 Signal Description
6 OS Open String (OS) alarm input for external battery disconnect switch; Alarms on
closure to the non-grounded “Battery” side of the DC bus (-48V).
7 FAJ General purpose Fuse Alarm Major (FAJ) alarm input; Major alarm on closure to
the non-grounded “Battery” side of the DC bus (-48V).
8 SHLF_ID3 Signal used for identifying the board. Pulled up or down on board accordingly in
the factory.
9 RS485+ B Inverting Driver Output / Inverting Receiver Input
10 RS485- A Non-inverting Receiver Input/ Non-inverting Driver Output
J2
Provides the contactor management interface for control and LVD status.
Table 38 QS871 J2 Signal Description
Pin # Signal Name Signal Description
1 LVD_COIL Positive voltage applied to Low Voltage Disconnect Coil. Connect to positive
side of contactor coil.
2 LVD_COILRTN Contactor coil return to VBUS- potential through circuitry. Connect to most
negative side of Contactor coil, other side of coil connected to VBus(+).
3 LVD _NC Normally Closed contactor status monitor. Closed to LVD_C when contactor is
open. Connect signal to NC pin of micro- switch of Contactor.
4 LVD_NO Normally Open contactor status monitor indicator. Closed to LVD_C when
contactor is closed. Connect signal to NO pin of micro-switch of contactor.
Note: The common or return of the micro switch for these signals must be attached to Vbus- in the system
outside of this board.
J3
Connection that provides field access to External Auxiliary Fuse Alarm Major and the Remote LVD input.
Table 39 QS871 J3 Signal Description
Pin # Signal Name Signal Description
1 Remote LVD External contact closure for remote disconnecting attached LVD; Disconnects
LVD on a dry contact closure to Remote LVD Return when feature is enabled.
2 Remote LVD
Return Protective (PTC or resistive) return to NE common for External Remote LVD
contact closure input signal.
3 Aux_Alarm General purpose Fuse Alarm Major (FAJ) alarm input; Major alarm on closure
to the non-grounded “Battery” side of the DC bus Battery (-48V).
J100 and J101
Provides connectivity to the RS485 GP rectifier/converter bus as well as a pass through to the next RS485
connected device.
Table 40 QS871 J100 and J101 Signal Description
Pin # Signal Name Signal Description
1 RS485+ B Inverting Driver Output / Inverting Receiver Input
2 RS485- A Non-inverting Receiver Input/ Non-inverting Driver Output
3 RS485REF RS485 Reference/return. Pass-through on this board.
4 No Connection
5 - Connects between J101.5 and J100.5. Connection reserved for1-Wire
communication signal in the system.
6 - Connects between J101.6 and J100.6. Connection reserved for1-Wire +5V
signal in the system.
