Pulsar Plus Controller Family
Issue 7 December 2011 150
Table 63 T1.317 Input Management Related Commands
obj,attr Description sta cha ope type Range of Values
inmnn,stt Input state  text 0=not alarming 1=alarming
inmnn,typ Input alarm type   text "" – no alarm, for in006, this value
allows the input to be used
for either group standby or
PBT. Polarity is ignored.
"FAN1" - drives FAN1 alarm
"FAN2" – drives FAN2 alarm
"FAJ1" – drives FAJ1 alarm
"FAJ2" – drives FAJ2 alarm
"OSA1" – drives OSA1 alarm
"AMJ1" – drives AMJ1 alarm, not
valid for NE872 or other LVD
card inputs.
"AUX1" – drives AUX1 alarm
"AUX2" – drives AUX2 alarm
“AUX3" – drives AUX3 alarm
“AUX4" – drives AUX4 alarm
“AUX5" – drives AUX5 alarm
“AUX6" – drives AUX6 alarm
"REMLVD" – Active signal opens
battery contactors for built-in
plant input, or for LVD inputs,
it opens the contactor on the
card where the signal is
active.
inmnn,pol Input alarming state   text CLOSED, OPEN
where: m is the distribution interface module ID from 1 to 4
nn is the input number from 01 to the number of inputs supported by the distribution interface
module
Built-in plant inputs
Object Signal Name Default Description
In001 FAJ1 Fuse Alarm Major 24V
In002 FAJ2 Fuse Alarm Major 48V
In003 AUX_PMJ Auxiliary Major Alarm
In004 OS_BATT Open String
In005 EPO_IN Emergency Power Off
In006 PBT_IN Group Standby/PBT
In007 AUX1_IN Air Conditioner Fail
In008 AUX2_IN Door Open
In009 AUX3_IN High External Ambient
In010 AUX4_IN Low External Ambient
Table 64 T1.317 Call-Out Manager Related Commands
obj,attr Description sta cha ope type Range of Values
cm1,des Description   text 30 char (Call-Out Manager)
cm1,ngi NAG Interval   Number 15 to 60 minutes
